| 影音天地主旨 ﹝請按主旨作出回應﹞ 下頁 尾頁 | 寄件者 | 傳送日期
|
| [#1] klangfilm 請問Klangfilm FE40是否可用FE86膽? 那地方有得買? 幾錢對。此機有壞，那地方可修理? 最後修改時間: 2010-08-07 16:59:29 |
chuty 正式會員61.xxx.xxx.50 |
2010-08-07 16:57 | |
|
|
|||
| [#2] klangfilm They are different sockets. Don't suggest to change it. Which model do you have? |
41450686 正式會員 61.xxx.xxx.7 |
2010-08-07 17:38 |
| [#3] klangfilm Thank, 41450686 hing! 6SELA 2798 此網站是否說明可代用EF86膽，或有甚麼代用膽? http://www.tube-classics.de/TC/Tubes/Common%20EF40/EF40.htm 最後修改時間: 2010-08-07 18:55:54 |
chuty 正式會員 61.xxx.xxx.50 |
2010-08-07 18:53 |
| [#4] klangfilm Not really, electrically is the same but they uses different socket. EF40 is rimlock 8pin, EF86 is 9pin. Normally, EF40 is better than EF86 so no reason to change. For me, I just want to change EF86 to EF40. EF40 is very nice. I think you need to modify the output transformer to 8ohm. Mostly you need to change the power capacitor in this circuit. Be careful the capacitor with the plastic cap, it has high voltage on the surface. It uses two EL34s outputs 100W. It makes the EL34 easy to die. |
41450686 正式會員 61.xxx.xxx.7 |
2010-08-07 23:22 |
| [#5] klangfilm Sham Shui Po 有個師傅修理古董Klangfilm的，你上去問問 最後修改時間: 2010-09-23 03:47:58 |
jn705 正式會員 219.xxx.xxx.49 |
2010-09-23 03:46 |
| [#6] klangfilm nice to see klangfilm friend here, I am not alone.  |
audiowen 正式會員 180.xxx.xxx.10 |
2010-09-23 11:17 |
| [#7] klangfilm EF40 is electrically similar to EF86 but with different pin out. Plug EF86 in to replace EF40 will result in permanent damage to your amp and maybe yourself as well! |
timtube 正式會員 116.xxx.xxx.94 |
2010-09-23 11:25 |
| [#8] klangfilm 2798 is a Siemens 6S-Ela series power amp. It is not a Klangfilm. |
timtube 正式會員 116.xxx.xxx.94 |
2010-09-23 12:04 |
| [#9] klangfilm Klangfilm never made any tube. EF40 were made by Siemens, Valvo, Lorenz and Tugsram, Mullard and Philips only. |
timtube 正式會員 116.xxx.xxx.94 |
2010-09-23 12:55 |
| [#10] klangfilm 各klangfilm師兄 請問你地係用咩pre amp推klangfilm 讓小弟作參考 |
AP100 正式會員 202.xxx.xxx.213 |
2012-02-14 13:46 |
| [#11] klangfilm The best pre-amp driving Klangfilm power amp I heard is Siemens/Klangfilm 2154 pre-amp.  |
timtube 正式會員 199.xxx.xxx.229 |
2012-02-14 14:50 |
| [#12] klangfilm 本人是用2754推Roger3/5a 15ohm preamp Dynaco PS2 經一輪換胆經驗後 感覺非常唔錯 亦發覺klangfilm推3/5a不失為一個好嘅配搭 |
AP100 正式會員 121.xxx.xxx.69 |
2012-02-14 15:17 |
| [#13] klangfilm 6S-ELA 2754 is made by Siemens and not Klangfilm, but they are closely related. I have heard Klangfilm KL-V502, KL-V408, KL-V408A, and KL-V410 driving 15 ohm LS3/5A and they are clearly among the best I heard. |
timtube 正式會員 199.xxx.xxx.229 |
2012-02-14 15:39 |
| [#14] klangfilm timtube兄 pre-amp2154雖要改嗎 因我的2754要加一對輸出牛變4 8 16 ohm 請指教 |
AP100 正式會員 121.xxx.xxx.133 |
2012-02-14 15:47 |
| [#15] klangfilm Original Klangfilm 2154 has no power supply on its own. Therefore, you need to do on of the following: 1. Build a link to allow the 2154 to draw power from your 2754; or 2. Build/use a separate external power supply; or 3. Build an internal power supply inside each of the 2154. We also need to build an interface box to accept input and output via RCA. |
timtube 正式會員 199.xxx.xxx.237 |
2012-02-14 16:11 |
| [#16] klangfilm 明白 多謝寶貴意見 如有幸到府上家訪就更清楚 更珍貴 |
AP100 正式會員 121.xxx.xxx.133 |
2012-02-14 16:22 |
| [#17] klangfilm 曾在朋友家聽過KL-V502推一對15吋Altec608G 感覺力大無窮但粗聲 pre-amp ARC sp11 |
AP100 正式會員 121.xxx.xxx.133 |
2012-02-14 16:59 |
| [#18] klangfilm KL-V502 is maybe too powerful for Altec, unless the room is as big as a cinema. KL-V203 is more appripriate.  |
timtube 正式會員 199.xxx.xxx.229 |
2012-02-14 17:31 |
| [#19] klangfilm 照你咁講就算3/5a都不宜用v502推 可能一樣會粗聲 反宜細power機會更適合 係嗎timtube師兄 |
AP100 正式會員 121.xxx.xxx.77 |
2012-02-14 17:55 |
| [#20] klangfilm In general, the larger the speaker, the less power you need. And the smaller the speaker, the more power you need. I was never impressed with SS amp driving LS3/5A except one time when I heard it driven by 2000W Class A SS monoblock the size large than a refrigerator. If you really want to drive LS3/5A well with SS amp, 1500W is minimum IMHO. You do not need that much power with tube amp but 20W is the mininum in general with LS3/5A. |
timtube 正式會員 199.xxx.xxx.229 |
2012-02-14 18:10 |
